| Resolution |
203dpi,300dpi |
| Printing method |
Direct Thermal and Transfer Thermal |
| Max. print speed |
6ips |
| Max. print width |
4.1"(104mm) @ 203dpi, 4.17"(106mm) @ 300dpi |
| Max. print length |
90"(2,286mm) @ 203dpi, 60"(1,524mm) @ 300dpi |
| Physical dimension(W x H x D) |
10.39"(264mm) x 13.5"(343mm) x 18.19"(462mm) |
| Weight |
28lbs(12.5kg) |
| Processor |
32-bit RISC CPU |
| Memory |
128 MB Flash / 32 MB RAM |
| Interface |
Standard: Serial RS232, USB-B, USB Host, and Ethernet 10/100Base T
Optional: Wi-Fi802.11a/b/g/n(factory option) |
| WiFi security encryption |
WEP 40/128bit, WPA Personal (PSK), WPA2 Personal (PSK) Enterprise (AES CCMP) |
| WiFi security authentication |
EAP-TLS, EAP-PEAP |
| Power |
Auto Range 100 ~ 240 AVC (48 ~ 62 Hz) |
| User interface |
1 power switch
8 operation buttons(menu,feed,pause,up,down,back,enter,calibration)
4 LEDs with 3 colors
3.5" color TFT display |
| Sensors |
Gap transmissive sensor
Black mark reflective sensor (position adjustable)
Head open sensor
Ribbon end sensor |
| Internal fonts |
8 resident expandable ZPL II bitmap fonts
Simplified Chinese, Traditional Chinese
Downloadable objects include graphics, scalable and bitmap fonts, label templates and formats
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software control
Code Page 1250, 1251, 1252, 1253, 1254, 1255, 1256 Support with font 0 |
| Graphic formats |
PCX,BMP |
| Bar code |
1D barcode: UPC-A, UPC-E, Codabar, CODE128, CODE39, CODE93, EAN-8, EAN-13, UCC/EAN128, POSTNET, ITF14, MSI, Plessey, Telepen, GS1 DataBar, German Post Code, Interleaved 2 of 5, Standard 2 of 5, Industrial 2 of 5, CODE11, EAN14
2D barcode: PDF417, Data Matrix, Maxicode, QR Code, MicroPDF471, Aztec |
| Font and barcode rotation |
0, 90, 180, 270 degree |
| Printer Language |
ZPL-II, TSPL, DPL, EPL2 |
| Media type |
Continuous, die-cut, black mark, fan-fold, notch |
| Media handling |
Standard: Continuous, Tear-Off / Options: Peel-Off, Cut, and Rewind |
| Media width |
Min 0.98"(25mm)/ Max 4.7"(120mm) |
| Media thickness |
0.002"(0.06mm) to 0.010"(0.250mm) |
| Media core diameter |
1.5"(38.1mm) |
| Media max. roll diameter |
10.0"(254mm) |
| Media length |
Min.: Tear-Off 0.31"(8mm)
Min.: Peel-Off , Cutter 1.0"(25.4mm)
Max.: 90"(2,286mm) @ 203dpi, 60"(1,524mm) @ 300dpi |
| Ribbon type |
Wax, Wax/Resin, Resi |
| Ribbon length |
1476.4 ft(450m) |
| Ribbon core diameter |
1.0"(25.4mm) |
| Ribbon width |
Min 1.18"(30mm)/ Max 4.33"(110mm) |
| Environment condition |
Operating Temperature: 41° to 122°F (5° to 50°C) (limitations based on selected media) / Operating Humidity: 25 to 85% RH Non-Condensing
Storage Temperature: -4° to 140° F (-20° to 60° C) / Storage Humidity: Non-Condensing |
| Safety Certification |
CCC, FCC, CE, BSMI, Energy Star |
| Environmental concer |
RoHS, WEEE |
| Options |
Wi-Fi802.11a/b/g/n/ac(factory option)
Rewind
Peel
Guillotine cutter |
